Requirements
Product | Specification/mm |
Nd:glass | 3.0% φ10×100 mm |
Process Indicators
- Product: Nd phosphate glass rod, equivalent to LHG-8
- Nd3+ concentration: 3.0wt.%
- Lasing wavelength: 1053nm
- Optical quality grade: SIQ grade
- Dimensions: 10(+/-0.1)mm dia aperture x 100(+/-0.5)mmL
- CA: > 9mm dia
- Both apertures: Flat, laser quality polished (lambda/10), AR@1053nm(R<0.3%/surface)
- AR coating LIDT: Durable at 30J, 0.5ms pulse, multimode, 0.02Hz(1PPM) repetition, 1053nm
- Coating adhesion test: Need to verify that the coating has passed a scotch 610 tape test
- S/D: 40/20 after coating (10/5 best effort)
- Barrel: Fine ground
- Parallelism: <10arcsec
- Perpendicularly: <5arcmin
- Warranty term: 1 year + 6 months after shipping product
